15 GB
Required cords
A Speaker cords (supplied)
(+)
B Monaural audio cord (supplied)
Black
(–)
* If you have an additional front speaker system, connect them to the SPEAKERS FRONT B terminals. You can
select the front speakers you want to use with the SPEAKERS (OFF/A/B/A+B) button. For details, see “Selecting
the speaker system” (page 40).
AUDIO
OUT
FRONT A
CENTER FRONT B
L R
L R
L R
+ + – –
–
SPEAKERS
SUB
WOOFER
A
E e
A
E e
A
E e
E e
A
INPUT
B
E e
A
SPEAKERS
FRONT B*
E e
A
SPEAKERS
SURROUND
L R
SURROUND BACK
+
Sub woofer
Center speaker Surround back
speaker
Front speaker
(left)
Front speaker
(right)
Surround speaker
(right)
Surround speaker
(left)
continued
