ASUS MAXIMUS V EXTREME
3-33
Chapter 3
3.5.7
Onboard Devices Configuration
Scroll down to view the other BIOS items.
HD Audio Controller [Enabled]
[Enabled]
Enables the High Definition Audio Controller.
[Disabled]
Disables the controller.
The following two items appear only when you set the Azalia HD Audio item to [Enabled].
Front Panel Type [HD]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC’97 or
high-definition audio depending on the audio standard that the front panel audio
module supports.
[HD]
Sets the front panel audio connector (AAFP) mode to high definition
audio.
[AC97]
Sets the front panel audio connector (AAFP) mode to legacy AC’97
SPDIF Out Type [SPDIF]
[SPDIF]
Sets to [SPDIF] for SPDIF audio output.
[HDMI]
Sets to [HDMI] for HDMI audio output.
