Sony STR-SL7 - Manual

STR-SL7
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT: POWER
REQUIREMENTS:
POWER
CONSUMPTION:
FRONT VIEW
Digital Audio
Receiver
120VAC
60Hz
BACK VIEW
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
SIDE VIEW
10 1/2"
1/2"
14 1/4"
3 1/4"
2 3/4"
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
7" 1 1/8"
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX (201) 930 7891 • b2b.sel.sony.com
16 7/8" X 3 1/4" X 11 1/ 2"
16 7/8 "
RMU-305S REMOTE CONTROL
R
11 1/2"
98W
1.7(stby)
Approx 7 lbs
AUX TV DVD
MULTI CH IN
FRONT SURR SUB
CNT
L
R
AM
FM
SUB OUT
SPEAKERS
FRONT SURR CNT
VIDEO MON
COAXIAL DIGITAL
IN DIGITAL
IN
AUDIO
IN VIDEO
OUT
L
R
R L R L
+
_
+
_
