SPECIFICATIONS
General:
LED Indicator Act/Link: Green
Power Requirement ♦
♦
♦
Operating Voltage: 5V DC
TX consumption: 250 mA (Max)
RX consumption: 150 mA (Max)
Physical specification ♦
♦
Weight: 25 g
Dimension: 98(L) x 30(W) x 14(H) mm
Supported OS ♦
♦
♦
♦
Windows 2000
Windows XP
Windows ME
Windows 98SE
Environment Specification ♦
♦
♦
♦
Operating Temperature: -5 ~ 45℃ ambient temperature
Storage Temperature: -20~70℃ ambient temperature
Operating humidity: 80% maximum (non-condensing)
Storage humidity: 80% maximum (non-condensing)
EMI Certification ♦
♦
♦
FCC Part 15 in US
EN300328 and EN300826 (EN301489-17) in Europe
DGT and BSMI in Taiwan
Wireless:
Standard IEEE 802.11g
Host Interface USB 2.0
Antenna Chip Antenna
Frequency Range 2.412GHz ~ 2.4835GHz
Number of Selectable Channels
USA, Canada: 11 channels
Japan: 14 channels
Europe: 13 channels
Modulation Technique
Direct Sequence Spread Spectrum (CCK, DQPSK, DBPSK)
Orthogonal frequency division multiplexing (OFDM)
Security
0/64/128 bit WEP
WPA
Media Access Protocol CSMA/CA (Collision Avoidance) with ACK
Output power
11g: 13.5 dBm
11b: 16.5 dBm
Data Rate
802.11g (54 Mbps, 48 Mbps, 36 Mbps, 24 Mbps, 18 Mbps, 12 Mbps, 9 Mbps, 6 Mbps)
802.11b (11 Mbps, 5.5 Mbps, 2 Mbps, 1 Mbps)
Throughput
20.3 Mbps @ 54Mbps
5.4 Mbps @ 11Mbps
Outdoor Distance
183M @54Mbps(FER<10%)
225M @11Mbps (PER<8%)
Sensitivity
-70dBm @54Mbps
-82dBm @11Mbps
