F. Controls, Indicators and Connectors
1. LCD Monitor and DVD Player (Refer to Figure 6)
Figure 6
11) Charge Indicator
12) Headphone Jack 1*
13) Headphone Jack 2
14) Volume Up/Down Control
15) Brightness Up/Down Control
16) LCD Panel Shut Off Switch
17) Wide Button
18) Previous/Next/Pause/Stop/Play
19) Menu Button
20) Up/Down/Left/Right/OK Button
1
2
4
5
6
7 8 9 10
11
12
13
14
15
16
17
18
19
20
1) Battery Release Button
2) DC 9V Input Jack
3) AV Jack
4) AV In/Out Switch
5) USB Port
6) Power ON/OFF Switch
7) SD/MMC/MS Card Slot
8) Power LED
9) Remote Control Sensor
10) Cover Open Switch
* Connecting to headphone jack number 1 will disable the
internal speakers
