Page 13
Chapter 1: Product Overview 3
Figure 1.1: Example DSR Switch Configuration
Figure 1.2: DSR Switch Model Comparison
Digital User
(Computer with Internet browser)
Analog User
(OSCAR Graphical
User Interface)
DSR Switch
Modem
Telephone
Network
Ethernet
DSView Server
Software
Model
Number
of
Servers
Digital
paths
Analog
User
DSR1020
16
1
1
DSR2020
16
2
1
DSR4020
16
4
1
DSR8020
16
8
1
DSR Switch
