13

Battery Unit (Front)

Processor Unit (Front/Top)

Processor Unit (Rear)

Micro USB jack

HDMI IN/MHL jack

WIRELESS (Wireless
Link) indicator

 (Power) indicator

Ventilation slot
(rear)

Ventilation slot (top)

/ (Power On/Standby) button

INPUT button

POWER indicator

PASS THROUGH indicator

 (Headphone) jack

HDMI INPUT 1/2/3 indicators

HDMI OUT (HMD) jack

WIRELESS (Wireless link)
indicator

HDMI IN 1/2/3 jacks

DC IN 8.4V jack

HDMI OUT (TV) jack
