TV Controls and Connectors
Front Panel
PUSH OPEN
MENU
TV/VIDEO CANNEL VOLUME
POWER TIMER LAMP POWER/STANDBY
PUSH OPEN POWER POWER
MENU
TV/VIDEO CHANNEL VOLUME
TIMER LAMP
2 1 5 9 3 4 6 7 8
0 0
To open the panel
To open the front panel of your TV, push up the
panel door just under the “PUSH OPEN” mark.
