15
Introd
ucin
g the
TV
KDF-46E2000/KDF-50E2000/KDF-55E2000
2-681-559-12(2)
Recommended
Viewing Area Your viewing position may affect the picture quality.
For the best picture quality, install your TV within the areas shown below.
Never install the TV as follows
Air blown into cooling fan. Air circulation is blocked
✍ Do not install the TV near any ventilation, as it may affect the
normal TV operating temperature.
Model Viewing distance
KDF-46E2000 min. 6.2 ft. (approx. 1.9 m)
KDF-50E2000 min. 6.6 ft. (approx. 2.0 m)
KDF-55E2000 min. 6.8 ft. (approx. 2.1 m)
30 ˚
30 ˚
50 inches min
. 6.6 ft. (approx. 2.
0 m)
46 inches min.
6.2 ft.
(approx.
1.9 m
)
55 inches min. 6.
8 ft. (approx. 2.
1 m)
65. 65.
65 65 ˚
65 ˚
65 ˚
50 inches min
. 6.6 ft. (approx
. 2.0 m)
46 inches min
. 6.2 ft. (approx
. 1.9 m)
55 inches min
. 6.8 ft. (approx
. 2.1 m)
Horizontal Viewing Area Vertical Viewing Area
