DVI Connector
Pin Signal
1 TMDS data2-
2 TMDS data2+
3 TMDS data2/4 shield
4 TMDA data4-
5 TMDA data4+
6 DDC clock
7 DDC data
8 NC
9 TMDS data1-
10 TMDS data1+
11 TMDS data1/3 shield
12 TMDS data3-
13 TMDS data3+
14 +5V
15 Ground for +5V
16 Hot-plug detect
17 TMDS data0-
18 TMDS data0+
19 TMDS data0/5 shield
20 TMDS data5-
21 TMDS data5+
22 TMDS clock shield
23 TMDS clock+
24 TMDS clock-
