Agri-Fab 45-02932 - Manual (Page 3)

3
sHown Full sIZe
HarDware PaCKaGe - Full sIZe
O
P
20
40 60
80
100 0
NOT SHOWN FULL SIZE
Q
R
T
U
S
N
A
H
J
K
L
B C D
G
F
E
I
M
KeY QTY. DesCrIPTIon
A
8 Hex Bolt, 5/16" x 2"
B 2 Hex Bolt, 5/16" x 1-1/4"
C 2 Carriage Bolt, 5/16" x 1-1/4"
D 2 Screw, #10 x 3/8"
E 4 SEMS Nut, 5/16"
F 10 Nylock Nut, 5/16"
G 2 Flat Washer, 5/16"
H 4 Flat Washer, 3/4"
I 2 Lock Washer, #10
J 2 Washer, 5/16" Tooth Lock
K 1 Hitch Pin
KeY QTY. DesCrIPTIon
L 1 Hair Cotter Pin
M 2 Cotter Pin
N 2 Knob
O 1 Spray Gun Clip, Small
P 1 Spray Gun Clip, Large
Q 1 Pressure Gauge
R 2 Spacer
S 1 Coiled Hose Clamp
T 2 Gasket, 3/4" Garden Hose
U 2 Axle Clamp, 3/4"
