31
Additional Information
Tables of settings using LEVEL/SURR and SET UP buttons
You can make various settings using the LEVEL/SURR, SET UP buttons, cursor buttons, and +/–
buttons. The tables below show each of the settings that these buttons can make.
Press Press U or u to select Turn jog dial to select Page
LEVEL/SURR FRONT BALANCE –8 to +8 (1 increment steps) 22
SURR BALANCE –8 to +8 (1 increment steps)
CENTER LEVEL –10 dB to +6 dB (1 dB steps)
SURR LEVEL –10 dB to +6 dB (1 dB steps)
SUB WOOFER LEVEL –10 dB to +6 dB (1 dB steps)
LFE MIX LEVEL OFF, –20 dB to 0 dB (1 dB steps)
DYNAMIC RANGE COMP OFF, 0.1 to 0.9 (0.1 steps), STD, MAX
EFFECT LEVEL depends on the sound field (16 steps) 23
WALL TYPE S (–8 to +8), MID, H (–8 to +8) (1 increment steps)
REVERBERATION TYPE S (–8 to +8), MID, L (–8 to +8) (1 increment steps)
SET UP L R (FRONT) LARGE, SMALL 14
C (CENTER) LARGE, SMALL, NO
SL SR (SURR) LARGE, SMALL, NO
SW (SUB WOOFER) S.W. YES, S.W. NO
L R (FRONT) XX.X m 3 feet to 40 feet (1 foot steps)
C (CENTER) XX.X m 3 feet to 40 feet (1 foot steps)
SL SR (SURR) XX.X m 3 feet to 40 feet (1 foot steps)
SL SR (SURR) PL. XXX PL. SIDE, PL. BEHD.
SL SR (SURR) HGT. XXX HGT. LOW, HGT. HIGH
MULTI VI. TV, DVD, VIDEO, AUX, OFF 26
TUNER VI. TV, DVD, VIDEO, AUX, OFF
