Video Section
Outputs
VIDEO: 1 Vp-p 75 ohms
COMPONENT:
Y: 1 Vp-p 75 ohms
P
B
/C
B
, P
R
/C
R
: 0.7 Vp-p
75 ohms
HDMI OUT: Type A (19
pin)
Speakers
Front (SS-TS83)
Speaker system
2-Way 2-Driver + Passive
radiator, Magnetically
Shielded
Speaker unit
Tweeter: 50 mm (2 in)
cone type
Woofer: 65 mm (2
5
/
8
in)
cone type
Passive radiator: 65 mm
(2
5
/
8
in) cone type
Rated impedance
3 ohms
Dimensions (approx.)
113 mm × 830 mm × 84
mm (4
1
/
2
in × 32
3
/
4
in ×
3
3
/
8
in) (w/h/d)
315 mm × 1,015 mm -
1,335 mm × 315 mm
(12
1
/
2
in × 40 in - 52
5
/
8
in
× 12
1
/
2
in) (w/h/d) with
stand
Mass (approx.)
1.9 kg (4 lb 4 oz)
3.8 kg (8 lb 7 oz) with
stand
Center (SS-CT81)
Speaker system
Full range, Magnetically
Shielded
Speaker unit
30 mm × 60 mm (1
3
/
16
in ×
2
3
/
8
in) cone type
Rated impedance
3 ohms
Dimensions (approx.)
385 mm × 50 mm × 67 mm
(15
1
/
4
in × 2 in × 2
3
/
4
in)
(w/h/d)
Mass (approx.)
0.4 kg (15 oz)
Surround (DAV-HDX575WC/DAV-
HDX578W/DAV-HDX678WF) (SS-TS81)
Speaker system
Full range Bass reflex,
Magnetically Shielded
Speaker unit
65 mm (2
5
/
8
in) cone type
Rated impedance
3 ohms
Dimensions (approx.)
103 mm × 225 mm × 82
mm (4
1
/
8
in × 8
7
/
8
in ×
3
1
/
4
in) (w/h/d)
Mass (approx.)
0.7 kg (1 lb 9 oz)
Surround (DAV-HDX975WF) (SS-TS84)
Speaker system
Full range Bass reflex,
Magnetically Shielded
Speaker unit
65 mm (2
5
/
8
in) cone type
Rated impedance
3 ohms
Dimensions (approx.)
113 mm × 830 mm × 84
mm (4
1
/
2
in × 32
3
/
4
in ×
3
3
/
8
in) (w/h/d)
315 mm × 1,015 mm -
1,335 mm × 315 mm
(12
1
/
2
in × 40 in - 52
5
/
8
in
× 12
1
/
2
in) (w/h/d) with
stand
Mass (approx.)
1.7 kg (3 lb 12 oz)
3.6 kg (7 lb 15 oz) with
stand
Subwoofer (SS-WS82)
Speaker system
Subwoofer Bass reflex
Speaker unit
160 mm (6
3
/
8
in) cone type
Rated impedance
1.5 ohms
Dimensions (approx.)
225 mm × 395 mm × 325
mm (8
7
/
8
in × 15
5
/
8
in ×
12
7
/
8
in) (w/h/d)
Mass (approx.)
6.1 kg (14 lb 6 oz)
General
Power requirements
120 V AC, 60 Hz
Power consumption
DAV-HDX575WC
On: 170 W
Standby: 0.3 W (at the
Power Saving mode)
DAV-HDX678WF
On: 130 W
Standby: 0.3 W (at the
Power Saving mode)
DAV-HDX578W
On: 130 W
Standby: 0.3 W (at the
Power Saving mode)
DAV-HDX975WF
On: 130 W
Standby: 0.3 W (at the
Power Saving mode)
Output voltage (DIGITAL MEDIA PORT)
DC 5 V
Output current (DIGITAL MEDIA PORT)
700 mA
Dimensions (approx.)
430 mm × 85 mm × 420
mm (17 in × 3
3
/
8
in ×
16
5
/
8
in) (w/h/d) incl.
projecting parts
430 mm × 85 mm × 450
mm (17 in × 3
3
/
8
in ×
17
3
/
4
in) (w/h/d) with the
wireless transceiver
inserted
Mass (approx.)
5.2 kg (11 lb 8 oz)
