Abocom WUG2700 - Manual (Page 2)

SPECIFICATION
Standard IEEE 802.11g and 802.11b
Host Interface USB 2.0
USB Connector Type A-type USB2.0 connector
Antenna Connector Chip antenna
Frequency Range 2.400GHz ~ 2.4835GHz
Operating Frequency /
Channel
2.412~2.462GHz (Canada, FCC) / 11 Channels
2.412~2.484GHz (Japan, TELEC) / 14 Channels
2.412~2.472GHz (Euro, ETSI) / 13 Channels
Modulation Technique
Orthogonal frequency division multiplexing (OFDM)
Direct Sequence Spread Spectrum (CCK, DQPSK, DBPSK)
Security
64/128bit WEP
WPA
WPA2
802.1x and 802.11i
Media Access Protocol CSMA/CA (Collision Avoidance) with ACK
Output power
11g: 14dBm (Typical)
11b: 17dBm (Typical)
Data Rate
802.11g - 54, 48, 36, 24, 18, 12, 9 and 6Mbps with auto-rate
fall back
802.11b - 11, 5.5, 2, and 1Mbps with auto-rate fall back
Sensitivity
54Mbps: -68dBm
11Mbps: -80dBm
Working Mode
Ad-Hoc
Infrastructure
Power Consumption
Continuous transmission mode: 290mA at 5VDC (Max.)
Continuous Reception mode: 240mA at 5VDC (Max.)
Operation Temperature
Operating Temperature: 0~55℃ ambient temperature
Storage Temperature: -20~70℃ ambient temperature
Humidity
Operating humidity: 90% maximum (non-condensing)
Storage humidity: 90% maximum (non-condensing)
Regulatory Approval FCC, CE
Dimensions 71.5mm (L) × 19mm (W) × 7.9mm (H)
LED Indicator Link: Blue ACTIVE: Orange
OS Support Windows 2000/XP/ME/98/SE
Throughput
22Mbps@ 54Mbps
5.5Mbps@ 11Mbps
