F. Controls, Indicators, and Connectors
1. Unit View (Refer to Figure 3)
Figure 3
10) LCD Panel Shut Off Switch
11) Wide Button
12) Previous/Next/Pause/Stop/Play Button
13) Menu Button
14) Up/Down/Left/Right/OK Button
15) Charge Indicator
16) Headphone Jack 1*
17) Headphone Jack 2
18) Volume Up/Down Control
19) Brightness Up/Down Control 1) SD/MMC/MS Card Slot
2) Power LED
3) Remote Control Sensor
4) Cover Open Switch
5) DC 9V Input JackPower
6) AV Jack
7) AV In/Out Switch
8) USB Port
9) ON/OFF Switch
1 2 3 4
10
11
12
13
14
5
6
8
9 OF
F
O N
15
16
17
18
19
* Connecting to headphone jack number 1 will disable the
internal speakers
