Additional Information for Using Sony Wall-Mount Bracket (SU-WL500)
Installing the Wall-Mount Bracket
Install the Base Bracket and Mounting Hooks.
1 Open the Wall-Mount Bracket package and check for all the required parts
along with the Instructions.
2 Decide where you want to install your TV. Refer to the TV installation
dimensions table.
Dimension Table
Screen center point
(except
KDL-32EX *)
(KDL-32EX *
only)
Unit: inches (mm)
Model Name Display
dimensions
Screen center
dimensions
Length for each mounting angle
Angle (0°) Angle (20°)
       
XBR-60LX90 *
56 3 /
4
(1,440)
35 3 /
4
(906)
1 1 /
4
(31)
19 7 /
8
(503)
4 7 /
8
(121)
15 1 /
4
(386)
33 1 /
2
(850)
20 5 /
8
(521)
XBR-52HX909
49 3 /
4
(1,263)
30 5 /
8
(775)
3 1 /
8
(77)
19
(482)
4 3 /
4
(120)
13 3 /
4
(348)
29
(735)
20
(506)
XBR-46HX909
44 3 /
8
(1,124)
27 3 /
8
(695)
4 3 /
4
(118)
19
(482)
4 3 /
4
(120)
12 5 /
8
(320)
26
(659)
20
(506)
KDL-60NX80 *
56 3 /
4
(1,440)
35
(889)
1 1 /
4
(31)
19 3 /
8
(490)
4 7 /
8
(121)
15 1 /
8
(384)
33 1 /
4
(842)
20 1 /
4
(514)
KDL-55HX800
50 3 /
8
(1,278)
30 1 /
8
(765)
1 5 /
8
(41)
17
(431)
4 1 /
2
(113)
13 7 /
8
(352)
28 3 /
8
(719)
17 7 /
8
(452)
KDL-46HX800
42 3 /
4
(1,085)
25 7 /
8
(656)
3 3 /
4
(95)
17
(431)
4 7 /
8
(121)
12 3 /
4
(323)
24 3 /
8
(616)
17 7 /
8
(454)
KDL-40HX800
37 1 /
2
(952)
22 7 /
8
(581)
5 1 /
4
(133)
17
(431)
4 3 /
4
(120)
11 3 /
4
(297)
21 1 /
2
(546)
17 7 /
8
(454)
KDL-55HX701
53 3 /
4
(1,363)
32 1 /
2
(825)
31 /
32
(25)
17 3 /
8
(439)
6 5 /
8
(165)
16 5 /
8
(421)
30 5 /
8
(776)
19
(481)
KDL-46HX701
45 1 /
2
(1,154)
27 3 /
4
(704)
3 3 /
8
(84)
17 3 /
8
(439)
6 1 /
2
(162)
14 7 /
8
(377)
26 1 /
8
(662)
19
(480)
KDL-40HX701
40 3 /
8
(1,023)
24 3 /
4
(628)
4 7 /
8
(122)
17 3 /
8
(439)
6 3 /
8
(160)
13 3 /
4
(349)
23 3 /
8
(591)
18 7 /
8
(479)
