8
Follow the simple steps below to remove the
Subwoofer:
1
Disconnect all the cables from the TV.
2 Remove the 4 screws from behind the TV as
indicated below. Do not remove any other
screws from the TV.
3
Gently lay the TV (face down) onto a level and
stable surface covered with a thick and soft
cloth.
4 Secure the Mounting Hooks to the rear of the
TV. See page 9 for more details on Installing
the Wall-Mount Bracket and also the
Instruction Guide provided by the Wall-
Mount Bracket model for your TV.
~
• If an electric screwdriver is used, set the torque to
tighten at approximately 1.5 N·m {15Kgf·cm}.
If you decide to mount the TV on a wall, follow
the steps below to uninstall the metal neck
from the Subwoofer to improve its cosmetic
appearance.
1 Gently lay the Subwoofer (face down) to
remove the 4 screws of the metal neck.
2 Place the neck cover (supplied) into the
Subwoofer to cover the metal neck hole.
~
• The Subwoofer should not be installed on the wall.
