Supplied items - x2 dual access silver, Sil ver – Adder Technology ADDERLINK X2 User Manual
Page 4
3
Power supply
and country-
specific mains
cable
Self adhesive
rubber feet
Supplied items - X2 Dual Access Silver
REMO
TE
www
.adder
.com
TO LOCAL
POWER
SIL
VER
REMOTE X2 Silver module
Connection
to video
monitor
Power supply
connection
Switch bank to
determine certain
modes and
functions
Connection
to keyboard
Connection
to mouse
Connection to
RS232 serial
device
Connection
to LOCAL
module
Power
and signal
activity
indicator
Multi-cable for keyboard,
video and mouse
connections between
computer and LOCAL
module
Serial cable for
RS232 connection
between computer
and LOCAL module
LOCAL
www
.adder
.com
TO REM
OTE
PO
WER
CPU / KVM SWITCH
VIDEO OUT
DU
AL
ACCESS
SIL
VER
LOCAL X2 Dual Access
Silver module
Connection from
computer RS232
serial port
Optional
power supply
connection
Switch bank to
determine certain
modes and
functions
Connection
to REMOTE
module
Multi-cable
connection from
computer
Power
and signal
activity
indicator
Keyboard, video
and mouse
connections to
peripherals
Cut-out rack plate
and rack blanking
plate - can be used
for either the LOCAL
or REMOTE modules,
as required
