Sony VPL-VW70 - Manual (Page 12)

8
VPL-VW70
RemarksItem NumberDataItemUpper byteLower byteDataUpper byteLower byteUSER BIAS RED00h53hFFE2h to 001Eh (_30 to 30)Set/GetUSER BIAS GREEN00h54hFFE2h to 001Eh (_30 to 30)USER BIAS BLUE00h55hFFE2h to 001Eh (_30 to 30)Iris Sensitivity00h56hRecommend00hFast01hSlow02hIris Manual00h57h00h to 64h (0 to 100)xvColor00h5AhOff00hOn01hStatus Error01h01hNO ERROR00hGet onlyLAMP ERROR01hFAN ERROR02hCOVER ERROR04hTEMP ERROR08hD5V ERROR10hPOWER ERROR20hNVM Data ERROR80h25hLENS SHUTTER01hERRORStatus Power01h02hSTANBY00hSTART UP01hSTARTUP LAMP02hPOWER ON03hCOOLING104hCOOLING205hSAVING COOLING106hSAVING COOLING207hSAVING STABY08hLamp Timer01h13hUSE TIME0000h-FFFFh *1Sircs (15bit category)17hRefer to Table4-----00h00hSet only *2Sircs (20bit category)19hRefer to Table5-----00h00h1BhRefer to Table6-----00h00h*1 Example) In case the lamp timer indicates 1000H, return values are [03h] upper byte and [E8h] lower byte.
*2 It is corresponded to single command only. Pages: 1 … 10 11 12 13 14 … 18 wrong Brand wrong Model non readable See also other documents in the category Sony Projectors: VPH-D50Q (132 pages) KP 57WS520 (2 pages) KP 46WT520 (85 pages) KP 57WS520 (1 page) KDF-50E3000 (1 page) KDF-50E3000 (52 pages) KDF-50E3000 (2 pages) KP- 57WV600 (101 pages) KP- 65WV700 EN (101 pages) KP- 57WV600 (1 page) KP- 65WV700 (2 pages) KP- 65WV700 (100 pages) Data Projector CX155 (70 pages) SRX-T105 (43 pages) KP 65WS500 (1 page) KP-41S5 (78 pages) KP-61HS30 (80 pages) KDF-E55A20 (92 pages) KDF-E55A20 (2 pages) KF-50XBR800 (96 pages) KF-50XBR800 (1 page) KF-60XBR800 (1 page) Bravia KDS-60A3000 (51 pages) KDS-55A3000 (2 pages) KDS-55A3000 (51 pages) KDS-60A3000 (1 page) KDP-57WS655 (8 pages) KDP 51WS655 (1 page) KDP-57WS655 (113 pages) KDP-57WS655 (2 pages) KP-43T75A (92 pages) KP- 65WV700 (1 page) LMP-H700 (2 pages) KP 57HW40 (83 pages) KP 51HW40 (1 page) KP 51HW40 (81 pages) KDF-55/60 WF655 (2 pages) 421 (3 pages) KL-W9000 (88 pages) KL-W9000 (96 pages) GRAND WEGA KDF-WF655 series (132 pages) VPH-D50HTU (140 pages) SRX-R110CE (12 pages) BRAVIA VPL-HW10 (80 pages) KDS-60A2020 (2 pages) Sitemap Remarks
Item Number Data
Item Upper byte Lower byte Data Upper byte Lower byte
USER BIAS RED 00h 53h FFE2h to 001Eh ( _30 to 30) Set/Get
USER BIAS GREEN 00h 54h FFE2h to 001Eh ( _30 to 30)
USER BIAS BLUE 00h 55h FFE2h to 001Eh ( _30 to 30)
Iris Sensitivity 00h 56h Recommend 00h
Fast 01h
Slow 02h
Iris Manual 00h 57h 00h to 64h (0 to 100)
xvColor 00h 5Ah Off 00h
On 01h
Status Error 01h 01h NO ERROR 00h Get only
LAMP ERROR 01h
FAN ERROR 02h
COVER ERROR 04h
TEMP ERROR 08h
D5V ERROR 10h
POWER ERROR 20h
NVM Data ERROR 80h
25h LENS SHUTTER 01h
ERROR
Status Power 01h 02h STANBY 00h
START UP 01h
STARTUP LAMP 02h
POWER ON 03h
COOLING1 04h
COOLING2 05h
SAVING COOLING1 06h
SAVING COOLING2 07h
SAVING STABY 08h
Lamp Timer 01h 13h USE TIME 0000h-FFFFh *1
Sircs (15bit category) 17h Refer to Table4 ----- 00h 00h Set only *2
Sircs (20bit category) 19h Refer to Table5 ----- 00h 00h
1Bh Refer to Table6 ----- 00h 00h
*1 Example) In case the lamp timer indicates 1000H, return values are [03h] upper byte and [E8h] lower byte.
*2 It is corresponded to single command only.
