Specifications
O
ther
Pin assignment
INPUT A connector (HD D-sub 15-pin,
female)
Input signals and adjustable/
setting items
Adjust Picture... menu
z : Adjustable/can be set
– : Not adjustable/cannot be set
INPUT SETTING menu
z : Adjustable/can be set
– : Not adjustable/cannot be set
1 R/R-Y 9 N.C.
2 G/Y 10 GND
3 B/B-Y 11 GND
4 GND 12 DDC/SDA
5 GND 13 HD/C.Sync
6 GND (R) 14 VD
7 GND (G) 15 DDC/SCL
8 GND (B)
Item Input signal
Video
or S
video
(Y/C) Com-
ponent Video
GBR Com-
puter B&W
Contrast
z z z z z
Brightness
z z z z z
Color
z z z
– –
Hue
z
(NTSC
3.58/
4.43
only)
– – – –
Sharpness
z z z
–
z
RGB
Enhancer – – –
z
–
Gamma
Mode – –
z z
–
Color Temp.
z z z z z
Volume
z z z z z
Item Input signal
Video
or S
video
(Y/C) Com-
ponent Video
GBR Com-
puter B&W
Dot
Phase – – –
z
–
H Size – – –
z
–
Shift – – –
z
–
Scan
Converter – – –
z
(VPL-CS6:
lower than
VGA,
VPL-CX6/
EX1: lower
than
SVGA)
–
Wide
Mode
z z z
–
z
