Accell CARDIO PACER - Manual (Page 60)

60
1 233 1081 20 Meter 1
2 M5x10 DIN 7985 Screw 3
3 403 0058 20EU Adaptor, EU 1
403 0058 20USA Adaptor, USA
403 0058 20GB Adaptor, GB
403 0058 20AUS Adaptor, AUS
5 503 1032 20 Meter socket 1
(incl. 6, 7, 8, 10, 11, 41)
6 M6 DIN 125 Flat washer 2
7 M6x60 DIN 912 Screw 1
8 - Sleeve 1
9 103 1082 20 Meter socket seat 1
10 M6 DIN 985 Nylon nut 1
11 - Meter socket knob 1
12 203 1075 20 Handlebar post 1
13 M8x16 ISO 7380 Screw 6
14 M8 DIN 137A Spring washer 6
15 M8 DIN 127 Semi-circle washer 6
16 403 1183 Meter cable, upper 1
17 173 1151 20 Handlebar post cover 1
18 443 1015 Belt 1
19 653 0102 Crank screw + plug 2
20 17x1,0 DIN 471 C-clip 3
21 ø18/25x0,3t DIN 988 Flat washer 5
22 - Curve washer 2
23 523 409 85 Bearing 3
24 40x1,5 DIN 472 Flexible ring 2
25 343 1016 Drive pulley axle 1
26 653 0092 Screw 3
27 263 1011 Drive pulley 1
28L 353 1014 20 Crank L 1
28L 353 1015 20 Crank R 1
29 403 1137 Servo motor set 1
(including 67, 101)
30 M6x16 ISO 7380 Screw 2
31 M6 DIN 127 Spring washer 2
32 M6 DIN 125 Flat washer 2
33 303 1024 Flywheel complete 1
(incl. 1x39, 1x35, 1x23)
34 303 1027 Pulley and axle 1
35 - One-way bearing set 1
36 ø18/25x1t DIN 988 Flat washer 2
37 M5x10 DIN 7985 Screw 6
38 523 1035 Bearing housing 2
(incl. 1x39)
39 - Bearing 3
40 - Washer 2
41 ø8/16x2t DIN 125 Flat washer 1
42 203 1076 20 Handlebar set 1
(incl. 43, 44, 45, 46, 47,
54)
43 - Tightener 1
44 403 1185 20 Handpulse sensor 2
(incl. 45, 54)
45 - Handpulse wire 1
46 533 9027 20 End plug 2
47 213 1019 20 Foam grip 2
48 363 1011 20 Pedal pair + straps 1
49* M8x55 DIN 603 Allen head bolt 4
50* M8 DIN 125 Flat washer 4
51* M8 DIN 986 Nut 4
52* 533 1097 20 Locking knob 1
(incl. 53, 92)
53* - Sleeve 1
54 - Wire cover strip 1
55* M5x14 DIN 7985 Screw 2
56 103 1083 20 Front foot 1
(incl. 2x57, 2x59, 2x64,
2x60, 2x61, 2x62)
57 533 1098 20 Foot end cap, pair 2
58 - Washer for adjusting 2
59 533 1099 20 Adjusting cushion 4
(incl. 58)
60 533 1100 20 Transport wheel 2
(incl. 61, 62)
61 - Sleeve 2
62 - Snap locking 2
63 103 1084 20 Rear foot 1
(incl. 2x57, 2x28, 2x59)
64 - Nut 2
65 103 1086 20 Frame 1
66 403 1181 Sensor switch + wire 1
(incl. 90)
67 - Cable wire, lower 1
68 ø4,2x50 DIN 7981 Screw 6
69 M3x20 DIN 7985 Screw 2
70 ø4,2x19 DIN 7504 Screw 10
71 153 1047 20 Seat post 1
72 153 1035 20 Seat 1
73 173 1149 20 Front cover, L 1
74 173 1150 20 Front cover, R 1
75 693 1012 Seat post sleeve, front 1
(incl. 76)
76 - Seat post sleeve, rear 1
77 373 1038 20 Seat adjusting knob 1
78 513 1014 Belt tightener set 1
(incl. 1x79, 1x80, 1x81,
1x82, 1x83, 1x84, 1x85,
1x86, 1x89)
79 M8 DIN 985 Nylon nut 1
80 M8 DIN 9021 Flat washer 1
81 - Pulley 1
82 - Curve washer 1
83 M8 DIN 125 Flat washer 1
84 M8x20 ISO 7380 Screw 1
85 - Spring 1
86 M8 DIN 934 Nut 1
87 173 1147 20 Side cover, L 1
88 173 1148 20 Side cover, R 1
89 ø10/13,5x1t DIN 7603 Washer 2
90 - Sensor fix base 1
91 M4x10 DIN 7985 Screw 1
92* - Carriage bolt 1
93 533 9030 20 End plug of seat slider 1
(incl. 94, 98, 100)
94 - Screw fixing base 1
95 173 1158 20 Seat slider cover, lower 1
(incl. 96, 99)
96 ø3,5x13 DIN 7981 Screw 2
97 373 1057 20 Seat locking knob 1
98 - Screw 1
99 - Seat sliding tube cover 1
100 - Seat horizontal adj. tube1
101 - Power wire 1
- 423 1160 20 Label set 1
- 583 1047 20 Owner’s manual 1
- 553 1016 Center assembly kit 1
(incl. 1x20, 1x21, 1x22,
2x23, 2x24, 1x36)
- 553 1017 Flywheel assembly kit 1
(incl. 2x20, 4x21, 1x22,
1x23, 1x35, 1x36,
1x39, 2x40)
- 553 1019 20 Hardware kit (incl.*) 1
-* - Screwdriver 1
-* - Allen key 1
-* - Box spanner 1
