Appendix
Selected LED Display
Activity Meaning
Off Port is not selected.
On (Steady) The computer attached to the LED’s corresponding
port has the KVM focus.
Flashing (On and Off equal) The computer attached to the LED’s corresponding
port has the KVM focus and is being accessed in
Auto Scan mode.
Specifications
Function Specification
Power Consumption 180 mW
Computer Connections 2
Port Selection Push Button Switches; Hotkeys
LEDs On Line 2 (Orange)
Selected 2 (Green)
Connectors Keyboard 1 x 6 pin mini-DIN female (PS/2 style) - Console
2 x 6 pin mini-DIN female (PS/2 style) - CPU Ports
Mouse 1 x 6 pin mini-DIN female (PS/2 style) - Console
2 x 6 pin mini-DIN female (PS/2 style) - CPU Ports
Video 1 x HDB-15 female (std. VGA/SVGA) - Console
2 x HDB-15 male (std. VGA/SVGA) - CPU Ports
Resolution Up to 1920 x 1440; DDC, DDC2, DDC2B
Scan Interval 3, 5, 10, 20 Seconds
Conversion Keyboard PS/2
Mouse PS/2
Operating Temperature 5 - 40 o C
Storage Temperature -20 - 60 o C
Humidity 0 - 80% RH Non condensing
Housing Metal
Weight 420 g
Dimensions (L x W x H) 128 x 75 x 45 mm
- 12 -
2003-11-25
