8
A. TO REMOTE START THE VEHICLE:
When you want to start your vehicle,
1. Press
button once on the transmitter.
2. The parking lights will flash to indicate the remote start received the
signal.
3. The engine will start approximately 5 seconds.
4. Once the engine is running, after a couple of seconds the parking
light will turn on again and climate controls will activate and adjust
the vehicles interior temperature to your preset setting.
5. The vehicle will run for 5 to 30 minute cycle and automatically shut
down.
(SAFTEY START OPERATION:)
The safety start feature allows you to press the
button once before
the vehicle will remote start or remote shut down.
NOTE: The Remote Start Unit will not start the vehicle if any one of the
following conditions exists:
1. The hood is opened.
2. The brake pedal is pressed.
3. Move the optional remote start enable toggle switch to OFF position.
(If installed)
4. The gear selector is in any gear other then “PARK” or “NEUTRAL”
TO TURN OFF THE REMOTE START:
When the engine is running (by remote start), if you want to stop it,
1. Press
button once on the transmitter.
3. Press the brake pedal
The vehicle will shut down and turn off the parking light to indicate engine
stopped.
TO OVERRIDE VEHICLE FROM REMOTE START CONTROL:
To operate the vehicle while running from the remote start.
1. Insert the ignition key and turn it to “ON” (not the start) position.
2. Press the brake pedal.
Note: If the brake pedal is pressed before the key is in the ON
position, the engine will shut down.
TEMPORARY STOP FEATURE:
This feature allows the vehicle to remain running after the key has been
removed from the ignition. This feature is useful for occasions when you
wish to exit and lock the vehicle for short periods of time, but would like to
leave the engine running and the climate control on.
1. Before turning off the engine, press the
button once on the
transmitter. The parking lights will come on and the LED will flash 3
times to confirm Temporary Stop feature ‘ON’
2. Turn the ignition key to OFF position. (The engine will stay running.)
3. The engine will run until the pre-programmed time elapsed or
shutdown input is received.
