Chapter 3: Installation and Configuration 33
и
и
6. The configuration utility will search for the ADAM-4570/
ADAM-4571/EDG-4504 devices on your local network.
Figure 3-1 Configuration Utility
3.2 Configuring the ADAM-4570/ADAM-4571/EDG-4504 —
The Configuration Utility
The ADAM-4570/ADAM-4571/EDG-4504 provides easy
Windows configuration through Ethernet connection. This
Windows utility searches all the ADAM-4570/ADAM-4571/
EDG-4504 and devices on the network automatically and you
can configure various parameters for TCP/IP configuration eas-
ily. For secure administration, it can also restrict the access rights
for configuration to only one host PC to enhance network secu-
rity. With this secure function enabled, other PCs will not have
permission for configuration. The Windows utility consists of four
functional categories: System, Network, Port, and Security which
are presented on the toolbar of the configuration utility.
Note: When you have finished the configuration of these set-
tings for each category, please follow the steps described
below to make thse settings effective on the ADAM-4570/
ADAM-4571/EDG-4504.
