114
Cyclades-PR1000
Appendix B - Hardware Specifications
APPENDIX B HARDWARE SPECIFICATIONS
General Specifications
The Cyclades-PR1000 power requirements and environmental restrictions are listed in Figure B.1.
Power Requirements (external DC adapter)
Input voltage range
90-264 VAC, 0.5A
Input frequency range 50-60 Hz, single phase
Maximum input surge current 40A cold start
Power dissipation max. 18W
Safety UL1950, CUL, TUV EN60950
Line Conducted Noise FCC PART 15J CLASS B, CISPR 22 CLA
MTBF 80,000 HOURS
Output plug Standard DC plug, central pin positive, 2.1mm
Power Requirements (PR1000 case)
Input voltage range
5 VDC +/- 5%
Current consumption type 0.5A @ 5VDC
Power dissipation type 2.5W
Power dissipation max. 5W
Approvals FCC Class A, CE class A
Environmental Conditions
Operating temperature
10C to 44C / 50F to 112F
Relative humidity 5% to 95%, non-condensing
Operating Altitude 12,000 feet max. (3660 m)
FIGURE B.1 GENERAL SPECIFICATIONS
