– 15
HDS 7/11 Classic
*KAP HDS 8/17 *AU/
Classic *EU HDS 12/18 Classic
*KAP
Main Supply
Voltage
V 220 400-420 220
Current type Hz 1~ 60 3~ 50 3~ 60
Connected load kW 3,4 5,5 8,4
Protection (slow) a 16 16 32
Maximum allowed net impedance Ohm (0,321+ j0,200) -- (0,163+ j0,102)
Water connection
Max. feed temperature
°C 30 30 30
Min. feed volume l/h (l/min) 1000 (16,7) 1100 (18,3) 1500 (25)
Suck height from open container (20 °C) m 0,5 0,5 0,5
Max. feed pressure MPa (bar) 0,6 (6) 0,6 (6) 0,6 (6)
Performance data
Water flow rate
l/h (l/min) 350-700 (5,8-11,7) 400-800 (6,7-13,3) 600-1200 (10-20)
Operating pressure of water (using standard
nozzle) MPa (bar) 3-11 (30-110) 3-17 (30-170) 3-18 (30-180)
Max. excess operating pressure (safety valve) MPa (bar) 14 (140) 20,5 (205) 21,5 (215)
Steam flow rate l/h (l/min) 330-360 (5,5-6) 340-420 (5,6-7) 550-610 (9,1-10,1)
Max. operating pressure for working with steam
(using steam nozzle) MPa (bar) 3,2 (32) 3,2 (32) 3,2 (32)
Part no. of steam nozzle -- 2.885-039.0 2.885-119.0 2.885-120.0
Max. operating temperature of hot water °C 98 98 98
Working temperature steam operation °C 155 155 155
Detergent suck in l/h (l/min) 0-45 (0-0,75) 0-50 (0-0,8) 0-72 (0-1,2)
Burner performance kW 53 63 91
Maximum consumption of heating oil kg/h 4,6 5,3 7,7
Max. recoil force of hand spray gun N 17,9 24,3 37,6
Nozzle size -- 048 047 068
Values determined as per EN 60355-2-79
Noise emission
Sound pressure level L
pA
dB(A) 70 71 73
Uncertainty K
pA
dB(A) 2 2 2
Sound power level L
WA
+ Uncertainty K
WA
dB(A) 88 88 90
Hand-arm vibration value
Hand spraygun
m/s 2 1,1 1,0 1,5
Spray lance m/s 2 3,4 3,4 4,8
Uncertainty K m/s 2 1,0 1,0 1,0
Fuel
Fuel
-- Fuel oil EL or Diesel Fuel oil EL or Diesel Fuel oil EL or Diesel
Amount of oil l 0,75 0,75 1,0
Oil grade -- 0W40 SAE 90 SAE 90
Dimensions and weights
Length x width x height
mm 1330 x 750 x 1060 1330 x 750 x 1060 1330 x 750 x 1060
Weight without attachments, M/S kg 146 155 178
Weight without attachments, MX/SX kg 154 163 185
Fuel tank l 25 25 25
Detergent Tank l 10+20 10+20 10+20
38 EN
