Technical specifications
Type IVC 60/12-1 Ec H Z22
Mains voltage V 220-240
Frequency Hz 1~ 50/60
Rated power W 1000
Container capacity l 60
Air quantity (max.) with a suction hose length of 3 m m 3 /h 140
Air quantity (max.) with a suction hose length of 10 m m 3 /h 108
Negative pressure (max.) kPa (mbar) 22,3 (223)
Type of protection -- IP 54
Protective class -- I
Suction hose connection (C-DN/C-ID) DN 72
Nominal width of suction hose DN 42
Length x width x height mm 970 x 690 x 995
Filter area m 2 0,95
Typical operating weight kg 59
Ambient temperature °C -10...+40
Relative air humidity % 30-90
Ignition protection class II 3D 95 °C
Values determined to EN 60335-2-69
Sound pressure level L
pA
dB(A) 76
Uncertainty K
pA
dB(A) 1
Hand-arm vibration value m/s 2 <2,5
Uncertainty K m/s 2 0,2
Power cord H07RN-F 3x1,5 mm 2
Part no.: Cable length
EU 6.649-915.0 10 m
