- 3
ƽ Danger
Risk of injury! While reversing, ensure that
there is nobody in the way, ask them to
move if somebody is around.
Caution
Risk of damage. Only use the direction
switch when the machine is standing still.

Set the travel direction switch to "back-
wards".
 Press accelerator pedal down slowly.
– The accelerator pedal can be used to
vary the driving speed infinitely.
– Avoid pressing the pedal suddenly as
this may damage the hydraulic system.
– In the event of power loss on inclined
surfaces, slightly reduce the pressure
on the accelerator pedal.
 Release the accelerator pedal, the ma-
chine brakes automatically and stops.
Note: The braking effect can be supported
by pressing the brake pedal.
Driving over fixed obstacles which are 70
mm high or less:

Drive forwards slowly and carefully.
Driving over fixed obstacles which are
more than 70 mm high:

Only drive over these obstacles using a
suitable ramp.
 Push the motor speed adjustment all
the way to the rear.
 Press brake pedal and keep it de-
pressed.
 Lock parking brake.
 Turn ignition key to "0" and remove it.
You will find complete specifications in the
operating instructions.
5.964-132.0 (KM 170/600 R D)
Reverse drive
Driving method
Brakes
Driving over obstacles
Turn off the appliance
Technical specifications
KM 170/600 R D
Machine data
Drive speed, forward km/h 14
Drive speed, reverse km/h 14
Climbing capability (max.) -- 18%
Usage duration when tank is full h 4,5
Amount of oil l 3,4
Operating speed 1/min 2000
Dry run speed 1/min 1300
Oil grades
Engine (above 25 °C) -- SAE 30, SAE 10W-30, SAE 15W-40
Engine (0 to 25 °C) -- SAE 20, SAE 10W-30, SAE 10W-40
Engine (below 0 °C) -- SAE 10W, SAE 10W-30, SAE 10W-40
Hydraulics -- HV 46
Tyres
Size, front -- 6.00-8
Air pressure, front bar 8
Size, rear -- 5.00-8
Air pressure, rear bar 8
Working conditions
Temperature °C -5 and +40
Dimensions and weights
Length x width x height mm 2742 x 1904 x 2213
Right turning radius mm 2525
Left turning radius mm 2490
Unladen weight kg 1695
Permissible overall weight kg 2701
Permissible front axle load kg 1703
Permissible rear axle load kg 998
Capacity of fuel tank, diesel l 26
8 EN
