6
English
Please read and comply with
these instructions prior to the
initial operation of your appliance. Retain
these operating instructions for future refer-
ence or for subsequent possessors.
The additional side brush provides inten-
sive cleaning for the right or left edge areas
due its larger extension.
A Joystick
B Rotation direction of the side brush
C End position of the side brush
D Regulating valve of the water volume
(stepless)
1 Transport drive
2 Work position left
3 Work position right
4 Position for maintenance procedures
Î Loosen the clamping screw.
Î Raise lock.
Î Align side brush.
Î Tighten clamping screw.
Function
Operating field
Start up
Align side brush
