– 2
1 Fleece filter bag
2 Suction support
3 Suction hose
4 Nameplate
5 Carrying handle
6 Cable clamp
7 Power cord
8 Suction head
9 Storage for accessories
10 Suction head lock
11 Steering roller
12 Dirt receptacle
13 Main switch
14 Switch between hard surface/carpet
15 Floor nozzle
16 Suction tube
17 Suction force regulator (continuous)
18 Bender
19 Main filter basket
20 Motor protection filter
21 Grid of the motor protection filter
The appliance can be operated in 2 ways:
1 Operation with fleece filter bag or paper
filter bag (option)
2 Operation without filter bag
Check whether main filter basket has
been inserted into the appliance.
Release and remove the suction head.
Remove the main filter basket.
Install the fleece filter bag or the paper
filter bag (option).
Insert main filter basket.
Insert and lock the suction head.
Plug in the mains plug.
Switch on the appliance at the main
switch.
Set the selection switch of the floor noz-
zle to hard surface or carpet.
Regulate the suction force on the suc-
tion force regulator (continuous).
Perform the cleaning operation.
Switch off the appliance at the main
switch.
Pull out the mains plug.
Empty the container.
Vacuum and wipe the appliance inside
and outside with a damp cloth.
ṇ CAUTION
Risk of injury and damage! Observe the
weight of the appliance when you transport
it.
When transporting in vehicles, secure
the appliance according to the guide-
lines from slipping and tipping over.
ṇ CAUTION
Risk of injury and damage! Note the weight
of the appliance in case of storage.
This appliance must only be stored in inte-
rior rooms.
ƽ DANGER
First pull out the plug from the mains before
carrying out any tasks on the machine.
Main filter basket (washable), clean it
under running water if necessary.
ATTENTION
Risk of damage! Never insert the main filter
basket while wet.
Device elements
Start up
Installation of the filter bag
Operation
Turning on the Appliance
Cleaning operations
Turn off the appliance
After each operation
Transport
Storage
Maintenance and care
Clean main filter basket
10
EN
