– 2
1 Nameplate
2 Power cord
3 Holder for suction pipes
4 Holder for crevice nozzle
5 Drain hose
6 Suction hose
7 Suction head lock
8 Socket
9 Wheel
10 Chassis
11 Dirt receptacle
12 Steering roller
13 Chassis handle
14 Suction support
15 Floor nozzle
16 Suction tube
17 Main switch
18 Suction head
19 Carrying handle
20 Cable hook
21 Bender
22 Cartridge filter
23 Fastening nut
24 Float
Caution
For dry vacuuming, the cartridge filter must
always be installed.
– When vacuuming fine dust, you may
also use an additional paper filter bag or
a membrane filter (special accessory).
Illustration
Illustration

Release and remove the suction head.
 Insert the paper filter bag or the mem-
brane filter (special attachment).
 Insert and lock the suction head.
Illustration

Remove the brush strips.
 Install the rubber lips.
Note: The structured side of the rubber lips
must point outwards.
– If the appliance is used to vacuum wet
dirt the paper filter bag or the mem-
brane filter (special accessory) must al-
ways be removed.
 Release and remove the suction head.
 Turn the suction basket by 180° and
keep it aside.
 Loosen the mounting nuts
 Remove the cartridge filter.
Illustration

Insert the fastening nut and tighten it.
 Install the additional filter.
 Insert and lock the suction head.
Illustration
The suction hose is equipped with a clip
system. All C-35/C-DN-35 accessories can
be connected.
 Plug in the main plug.
 Switch on the appliance at the main
switch.
Device elements
Start up
Dry vacuum cleaning
Inserting the paper filter bag
Wet vacuum cleaning
Inserting the rubber lips
Remove the paper filter bag
Installing an additional filter
Clip connection
Operation
Turning on the Appliance
