– 15
HDS 6/14-4 HDS 7/16
Main Supply
Voltage
V 230 400 230
Current type Hz 1~ 50 3~ 50 3~ 50
Connected load kW 3,6 4,7 4,7
Protection (slow) A 16 16 16
Type of protection -- IPX5 IPX5 IPX5
Protective class -- I I I
Maximum allowed net impedance Ohm 0.3617 --
Water connection
Max. feed temperature
°C 30 30
Min. feed volume l/h (l/min) 800 (13,3) 900 (15)
Suck height from open container (20 °C) m 0,5 0,5
Max. feed pressure MPa (bar) 1 (10) 1 (10)
Performance data
Water flow rate
l/h (l/min) 240-560 (4-9,3) 270-660 (4,5-11)
Operating pressure of water (using standard nozzle) MPa (bar) 3-14 (30-140) 3-16 (30-160)
Max. excess operating pressure (safety valve) MPa (bar) 17 (170) 19,5 (195)
Steam flow rate l/h (l/min) 240-290 (4-4,8) 270-305 (4,5-5,1)
Max. operating pressure for working with steam (using
steam nozzle) MPa (bar) 3,2 (32) 3,2 (32)
Part no. of steam nozzle -- 5.130-453.0 5.130-454.0
Max. operating temperature of hot water °C 98 98
Working temperature steam operation °C 155 155
Detergent suck in l/h (l/min) 0-33,6 (0-0,56) 0-39,6 (0-0,66)
Burner performance kW 43 51
Maximum consumption of heating oil kg/h 3,5 4,1
Max. recoil force of hand spray gun N 25,6 32,4
Nozzle size -- 035 040
Values determined as per EN 60355-2-79
Noise emission
Sound pressure level L
pA
dB(A) 73 77
Uncertainty K
pA
dB(A) 3 3
Sound power level L
WA
+ Uncertainty K
WA
dB(A) 91 95
Hand-arm vibration value
Hand spray gun
m/s 2 7,4 2,6
Spray lance m/s 2 5,3 4,2
Uncertainty K m/s 2 0,3 0,3
Fuel
Fuel
-- Fuel oil EL or Die-
sel
Fuel oil EL or Die-
sel
Amount of oil l 0,7 0,3
Oil grade -- 0W40 SAE 90
Dimensions and weights
Length x width x height
mm 1060 x 650 x 920 1060 x 650 x 920
Typical operating weight, C kg 118,6 118,1
Typical operating weight, CX kg 121,5 121
Fuel tank l 15,5 15,5
Detergent Tank l 15,5 15,5
39 EN
