– 14
Technical specifications
HDS 6/10 HDS 6/12 HDS 6/14
Main Supply
Voltage
V 100 230-240 230
Current type Hz 1~ 50 1~ 50 1~ 50
Connected load kW 2,9 3,0 3,6
Protection (slow) A 30 13 16
Type of protection -- IPX5 IPX5 IPX5
Protective class -- I I I
Maximum allowed net impedance Ohm 0.3710 0.3710 0.3710
Water connection
Max. feed temperature
°C 30 30 30
Min. feed volume l/h (l/min) 800 (13,3) 800 (13,3) 800 (13,3)
Suck height from open container (20 °C) m 0,5 0,5 0,5
Max. feed pressure MPa (bar) 1 (10) 1 (10) 1 (10)
Performance data
Water flow rate
l/h (l/min) 240-560 (4-
9,3)
240-560 (4-
9,3)
240-560 (4-
9,3)
Operating pressure of water (using standard noz-
zle) MPa (bar) 3-10 (30-100) 3-12 (30-120) 3-14 (30-140)
Max. excess operating pressure (safety valve) MPa (bar) 12 (120) 15 (150) 17 (170)
Steam flow rate l/h (l/min) 240-290 (4-
4,8)
240-290 (4-
4,8)
240-290 (4-
4,8)
Max. operating pressure for working with steam
(using steam nozzle) MPa (bar) 3,2 (32) 3,2 (32) 3,2 (32)
Part no. of steam nozzle -- 5.130-453.0 5.130-453.0 5.130-453.0
Max. operating temperature of hot water °C 98 98 98
Working temperature steam operation °C 155 155 155
Detergent suck in l/h (l/min) 0-33,6 (0-0,56) 0-33,6 (0-0,56) 0-33,6 (0-0,56)
Burner performance kW 43 43 43
Maximum consumption of heating oil kg/h 3,5 3,5 3,5
Max. recoil force of hand spray gun N 21,8 25,6 25,6
Nozzle size -- 043 042 036
Values determined as per EN 60355-2-79
Noise emission
Sound pressure level L
pA
dB(A) 76 76 76
Uncertainty K
pA
dB(A) 3 3 3
Sound power level L
WA
+ Uncertainty K
WA
dB(A) 94 94 94
Hand-arm vibration value
Hand spray gun
m/s 2 2,7 2,7 2,7
Spray lance m/s 2 5,4 5,4 5,4
Uncertainty K m/s 2 0,3 0,3 0,3
Fuel
Fuel
-- Fuel oil EL or
Diesel
Fuel oil EL or
Diesel
Fuel oil EL or
Diesel
Amount of oil l 0,3 0,3 0,3
Oil grade -- 0W40 0W40 0W40
Dimensions and weights
Length x width x height
mm 1060 x 650 x
920
1060 x 650 x
920
1060 x 650 x
920
Typical operating weight, C kg 108,1 108,1 108,1
Typical operating weight, CX kg 111 111 111
Fuel tank l 15,5 15,5 15,5
Detergent Tank l 15,5 15,5 15,5
38 EN
