MULTI-TASKER
3
ABOUT YOUR MT103-118/120 2
MT103-118/MT103-120
Dual 1-in 3-out Video & S-Video Distribution
Amplifier Card
The MT103-118/120 is a dual 1-in 3-out Composite
(C) Video and S-Video Distribution Amplifier (DA)
Card. There is one BNC C-Video input with three
BNC C-Video outputs and one S-Video input with
3 S-Video outputs. It is designed for use in
Multi-Tasker

enclosures. When installed in a
Multi-Tasker

enclosure, this DA card enables the
connection of a single S-Video and/or Composite
video source to up to three displays or recording
devices each. On the MT103-120, each output
may be individually enable or disabled through
RS-232 control.
A variety of video signal formats can be
accommodated by using multiple DA cards in a
Multi-Tasker

enclosure. For example, two
S-Video DA cards can be used to handle the two
components of an S-Video signal (Chroma and
Luma). To create a component S-Video distribution
amplifier, simply install three of the MT S-Video DA
cards, one each for the Y, Pr, and Pb (or Y, R-Y,
B-Y) signal components. Similarly, the MT S-Video
DA series cards can also be used to pass
computer video signals: 4 cards for RGBS and 5
for RGBHV.
The MT103-120 also features Equalization
adjustment. The equalization allows the user to
adjust the signal when long cable lengths are
involved. The Equalization circuitry is good for
cable runs up to about 250 feet when a high
quality 75 ohm coaxial cabled is used.
TECHNICAL SPECIFICATIONS 3
FEATURES/
DESCRIPTION
MT103-118/120
GENERAL
Inputs
S-Video Connectors
(1) 4-pin Mini-DIN Connector
C-Video Connectors (1) BNC Connector
Outputs
S-Video Connectors
(3) 4-pin Mini-DIN Connector
C-Video Connectors (3) BNC Connector
Approvals CE/FCC
Table 1. MT103-118/120 General
MECHANICAL MT103-118/120
Enclosure Slots
Required
One
Weight 0.43lb (0.19kg)
Shipping Weight 1 lb. (0.42kg)
Connector Panel Black
T° Operating 10°C-40°C
T° Maximum 0 to 50°C
Humidity 90% non-condensing
MTBF (calc.) 55,000 hrs
Table 2. MT103-118/120 Mechanical
ELECTRICAL MT103-118/120
Input Signals
Analog
+/- 1.5V(signal: 1.5V p-p)
Sync 0 to +5V
Impedance 75 Ohms
Type Differential
Return Loss -38dB @ 50MHz
Maximum DC Offset 10mV
Output Signals
Gain
10.5 (+/-5%)
Impedance 75 Ohms
Propagation Delay
(Sync)
4nS max.
Rise/Fall Time (Sync) 9nS max.
Differential Phase
Error
01°, @ 4.5 MHz
Bandwidth
MT103-118/120
350 MHz @-3dB
Power
Power
(from Enclosure)
+6V -6V
Power
Consumption
MT103-118/120 200mA 200mA 2.4 watts
Optional Accessories
MS8102CA
6ft, 15-pin HD Male to 5-BNC
Male
MS8112CA
6ft, 15-pin HD Female to 5-BNC
Male
MS8132MG
1ft, 4-pin mini DIN Male to 2-
BNC Male
MS8133MG
1ft, 4-pin mini DIN Female to 2-
BNC Male
Table 3. MT103-118/120 Electrical
