Multi-tasker – Altinex Video and S-Video Distribution Amplifier Cards MT103-118 User Manual
Page 11
MULTI-TASKER
10
Cause 2:
The MT103-118/120 card and its
serial device are not
communicating.
Solution 1: Turn the system OFF and then ON
again. If there is still an error, see
Cause 3.
Cause 3:
RS485 communication error
Solution 1: Make sure that the card is pushed
all the way into the slot. If there is
still an error, see Solution 2.
Solution 2: Turn the system OFF and then ON
again. If there is still an error, see
Solution 3.
Solution 3: Call ALTINEX at (714) 990-2300.
8.3 NO DISPLAY
Cause 1:
The source has a problem.
Solution:
Check the source and make sure
that there is a signal present and all
source connections are correct. If
the source is working and there is
still no display, see Cause 2.
Cause 2:
The card output is not selected.
Solution:
Select the card output. See RS-232
accessible commands in Section 7.
If no display is present, see
Cause 3.
Cause 3:
Cable connections to the
destination are incorrect.
Solution:
Make sure that cables are
connected properly. Also, make
sure that the continuity and wiring
are good. If there is still no display
present, see Cause 4.
Cause 4:
The display has a problem.
Solution:
Make sure that the display is
powered. If there is still no display,
call ALTINEX at (714) 990-2300.
ALTINEX POLICY
9
9.1 LIMITED WARRANTY / RETURN POLICY
Please see the Altinex website at
www.altinex.com
for details on warranty and
return policy.
9.2 CONTACT INFORMATION
ALTINEX, INC
592 Apollo street
Brea, CA 92821 USA
TEL: 714 990-2300
TOLL FREE: 1-800-ALTINEX
WEB:
www.altinex.com
E-MAIL:
