Configuration B
Select “Connect to external networks using wired ethernet”
Configuration C
Select “None”
Configuration D
Select “None”
In configurations B and D, only your PC and the InternetVue™ communicate wirelessly; the internet
connection to the gateway/router is wired. Wireless security can be enabled between the PC and
the InternetVue™ by clicking on the “Enable Display Encryption” checkbox (1).
The following window will appear. Enter 8 to
23 characters here. This will create a secure
connection between the InternetVue™ and
your PC.
1
