DISPLAY CABINET HEATED
15 P/N 1010677 Rev. D 12/99
A.J. Antunes & Co.
REPLACEMENT PARTS – DCH-20/22/30/32
1 0011002 Front Glass Panel Assy. 1 1 - - -
0011003 Front Glass Panel Assy. - - 1 1 1
2 0020922 Inner Lamp Housing Weldment 1 1 - - -
0020923 Inner Lamp Housing Weldment - - 1 1 1
3 0010706 Resistor Assy., 120V - 1 - - 1
0010664 Resistor Assy., 208V 1 - 1 1 -
4 0502895 Housing, Lamp 1 1 - - -
0502850 Housing, Lamp - - 1 1 1
5 0800236 Display Rack (Optional) 1 1 - - -
0500237 Display Rack (Optional) - - 1 1 1
6 0010704 Sliding Door Assy., Clear Glass 2 - - - -
0010705 Sliding Door Assy., Clear Glass - - 2 2 2
0011133 Sliding Door Assy., Mirrored Glass
(Mfg. No. 9020481 only)
- 2 - - -
7 0501820 Support, Center Pan 1 1 - - -
0501869 Support, Center Pan - - 2 2 2
8 0501965 Diffuser, Water Tray 2 2 - - -
0501966 Diffuser, Water Tray - - 2 2 2
9 0501807 Water Tray 2 2 - - -
0501866 Water Tray - - 2 2 2
10 0502172 Heat Shield 2 2 3 3 3
11 0020744 Control Panel Weldment 1 1 - - -
0020745 Control Panel Weldment 0 0 1 1 1
12 402K172 Temperature Control Display, 150°-165°F 1 - 1 - -
403K276 Temperature Control Display, 65°-75°C
(Mfg. Nos. 9020458/468/456/466 only)
- - 1 - -
7000118 Temperature Control Display, 100°-165°F - 1 - 1 1
13 4010110 Rocker Switch, Power On/Off 1 1 1 1 1
14 0900143 Side Glass 2 2 2 2 2
15 0020702 Heat Sink Assy. 1 1 1 1 1
16 4010142 Transformer, 240V/12V 1 - 1 1 -
4010159 Transformer, 120V/12V - 1 - - 1
17 405K125 Transformer, 230V/115V 1 - 1 1 -
18 4010159 Relay, Solid State 1 1 1 1 1
19 0010494 Ballast Assy., 20 Watt Lamp 1 1 - - -
0010495 Ballast Assy., 30 Watt Lamp - - 1 1 1
20 0502045 Retainer, Glass, LH** 1 1 1 1 1
0502044 Retainer, Glass, RH** 1 1 1 1 1
21 0020670 Top Cap Assy., LH** 1 1 1 1 1
0020669 Top Cap Assy., RH** 1 1 1 1 1
22 2100183 Door Track, Upper 1 1 - - -
2100185 Door Track, Upper 0 0 1 1 1
23 2100184 Door Track, Lower 1 1 - - -
2100186 Door Track, Lower - - 1 1 1
24 0501946 Grill, Blower 1 1 2 2 2
Item Part Description Qty. (240V) (120V)
No. DCH-20 DCH-22 DCH-30 DCH-32 DCH-32
* Only available in packages of 1 0.
** LH/RH is determined by viewing front of curved glass panel.
