VERTICAL CONTACT TOASTER
5
P/N 1010729 Rev. G 09/13
SPECIFICATIONS
Electrical Ratings
Electrical Cord & Plug Configurations
* Used in Model Designation
** Indicates that the plug comes with a Commercial cord
*** Indicates that the plug comes with a Harmonized cord
Model Designation
TYPE OF POWER CORD
H = HARMONIZED
C = COMMERCIAL
TYPE OF PLUG
V = NEMA 6-20P
F = NEMA 5-15P
T = NEMA 5-20P
C = CEE 7/7 Schuko
S = NEMA L6-20P
VCT-20XX
VCT-25XX
VCT-50XX
Model &
Mfg. No.
Volts
Watts
Amps
Hz
VCT-20CS
9200560
280-240
3200-4257
15.4-17.3
50/60
VCT-25CF
9200620
120
1760
14.7
60
VCT-25CT
9200622
120
1760
14.7
60
VCT-25CF
9200624
120
1760
14.7
60
VCT-25CF
9200630
120
1760
14.7
60
VCT-25CV
9200626
208-240
2600-3460
12.5-14.4
50/60
VCT-25HC
9200628
9200629
208-240
2600-3460
12.5-14.4
50/60
VCT-25CF
9200631
208-240
2600-3460
12.5-14.4
50/60
VCT-25CV
9200632
208-240
2600-3460
12.5-14.4
50/60
VCT-25HC
9200634
208-240
2600-3460
12.5-14.4
50/60
VCT-25CF
9200638
208-240
2600-3460
12.5-14.4
50/60
VCT-50CF
9200600
120
1760
14.7
60
VCT-50CT
9200602
120
1760
14.7
60
VCT-50CV
9200606
208-240
2600-3460
12.5-14.4
50/60
VCT-50HC
9200608
208-240
2600-3460
12.5-14.4
50/60
VCT-50CV
9200614
208-240
2600-3460
12.5-14.4
50/60
VCT-50HC
9200616
208-240
2600-3460
12.5-14.4
50/60
VCT-25HC
9200640
230
2400
10.4
50/60
Letter
Code*
Description
Configuration
C
H
Commercial Cord
Harmonized Cord
(H)C***
CEE 7/7, 16
Amp., 250 VAC
(Assembly Only).
(C)F**
5-15P, 15 Amp.,
120 VAC., Non –
Locking (Assembly
Only).
(C)T**
5–20P, 20 Amp.,
120 VAC., Non –
Locking (Assembly
Only).
(C)V**
6-20P, 20 Amp.,
250 VAC., Non –
Locking (Assembly
Only).
(C)S**
LS-30P, 30 Amp.,
120 VAC.,
Straight Twist Lock
WHT BLK
GRN
WHT BLK
GRN
R
R
30
A.
2
5
0
V
.
