10 ENGLISH
Prescribed usage
The ROCAM® Plus TV inspection system is intended exclusively for inspecting vacant and clean tubes,
hollow bodies and cavities, as stated under „Specifications / Fields of application“. No other use is
permissible.
All applicable standards and regulations must be complied with.
More specifically, these include:
⎯ Law governing technical equipment (equipment safety law) and appurtenant regulations
⎯ Low voltage directive
⎯ UVV VBG 1 "General regulations"
⎯ UVV VBG 4 "Electrical installations and operating equipment"
⎯ Directives governing work in containers and restricted areas (BG rule 77), directive on display
workstations.
Specifications / Fields of application
Description.................................................................................... ROCAM® Plus
Video input .................................................................................. BNC 1 k
Video output ................................................................................ BNC 75
Power consumption ..................................................................... 1500 mA
Ambient temperature .................................................................. -10 ... +50 °C
Storage temperature .................................................................... -30 ... +50 °C
Dimensions (L x W x H) ................................................................ 510 x 415 x 365 mm
Weight inc. battery ..................................... 6.9725=20kg,.6.9740=21kg,.6.9825=25kg,.6.9840=26kg
Monitor ....................................................................................... color display screen 5.6“
Camera module ........................................................................... type CMOS color PAL, NTSC
Camera head diameter ................................................................. ø 40 mm
Reel cable length ......................................................................... 60/100 m
Reel cable diameter ...................................................................... ø 7.5 mm
Battery voltage ............................................................................. 12 V
Battery capacity ............................................................................ 1.4 Ah
Tube ø ......................................................................................... > 40 mm
Tube ø with mini module ............................................................. > 25 mm
Scope of supply: ROCAM® Plus bag, power pack, Mini Module 1.3 Color, adapter for Mini Module 1.3
connector, 40/65 mm guide block for DN 70, 40/65 mm guide block for brush set Ø 100 mm and Ø 150
mm, 12 volt cigarette lighter adapter, test adapter for camera head seal test, battery, keyboard*,
professional pipe inspection software*, roller blocks for Ø 150 and 200 mm*.
*on 6.9740 and 6.9840
Operating instructions
Do not buckle the reel cable as it may break!
Do not pull the reel cable over sharp edges as they
may damage the cable!
Never aim jets of water on the front (display
screen/ control panel) of the equipment!
Power connection A
A new battery must be charged prior to using it for
the first time (approx. 7h).
If the battery is running low, the power supply unit
should be connected. The charging process takes
less time if the equipment is switched off.
The power supply unit can be connected
permanently. The battery cannot be overcharged.
Once the battery is sufficiently charged, the system
automatically switches to float charging.
When the power supply unit is connected the
batterycharge warning lamp is illuminated.
When the ROCAM®Plus is switched on the device
always switches to float charging irrespective of
the degree of charge or discharge of the battery.
