ENGLISH 11
Proper usage
ROMAX Compact:
The ROMAX Compact is designed exclusively for the use of pressing jaws manufactured by
ROTHENBERGER.
The device and the press jaws are designed exclusively for crimp fittings, for which the corresponding
pressing jaws have been designed. Any other or additional use shall be deemed improper.
ROTHENBERGER cannot accept any liability for the resultant consequences and damage, nor for the use of
pressing jaws from other manufacturers, neither for damage caused by these pressing jaws.
Proper usage also includes compliance with the operating manual, compliance with the inspection and
servicing conditions and adherence to all the relevant safety regulations.
The ROMAX Compact is a handheld electric machine and must not be used for stationary applications.
This device may only be used correctly as described.
Battery/Charger:
The quick charger can charge ROTHENBERGER batteries 14,4 V art.no. 15418.
This device may only be used correctly as described.
Technical data ROMAX Compact
Battery voltage ........................................................................ 14,4 V
Battery capacity....................................................................... 2,6 Ah
Rated power consumption....................................................... 280 W
Motor speed ........................................................................... 12000 1/min
Maximum piston force ............................................................ 19 kN
Pressing time .......................................................................... ca. 6 – 9 s
Dimensions (L x W x H) ............................................................ 380 x 70 x 90 mm
Weight (without battery) ......................................................... ca. 2,0 kg
Working range:
Metal system ................................................................... ø 12 - 28 mm
Plastic system .................................................................. ø 12 - 40 mm
Application temperature range ................................................ -10°C - 60 °C / 14°F – 140°F
Operating mode...................................................................... S 3
Typical acceleration in hand-arm area ...................................... ≤ 2,5 m/s²
Sound pressure level (L
pA
) ........................................................ 71 dB (A) ¦ K
pA
3 dB (A)
Sound power level (L
wA
) ........................................................... 82 dB (A) ¦ K
wA
3 dB (A)
The noise level during operation can exceed 85 dB (A). Wear ear protection!
Measurements found in compliance with EN 60745-1.
Technical data Battery / Charger
Battery: Charger:
Type ................................ ROTHENBERGER Li-Ion Mains voltage ..................... 220 - 240V / 110V
Voltage ............................ 14,4 V Mains frequency ................. 50 - 60 Hz
Capacity .......................... 2,6 Ah Max. output ........................ 70 W
Approx. charging time (90% full) ...... ca. 70 min Voltage range ..................... 7,2 - 24 V
Recharge battery pack before first use! Weight ............................... ca. 500 g
Pay attention to the mains voltage!
Check the label on the bottom of the
charger!
Deep discharge protection may influence empty
battery detection of the machine!
