20 ENGLISH
Contents Page
1 Safety notes 22
1.1 Correct use 22
1.2 General safety rules 22
1.3 Safety information 24
2 Technical data 24
3 Functions of the thread- machine 25
3.1 Overview (Fig. A) 25
3.2 Functional description 25
3.3 Accessories 25
4 Preparations for operation 25
4.1 Transporting the thread machine 25
4.2 Setting up the machine 26
4.3 Electrical connection 26
4.4 The thread oil 27
4.5 Checking the thread oil 27
4.6 Setting the supplied thread oil quantity 27
4.7 Draining off the oil 28
5 Operation of the thread machine 28
5.1 Clamping the workpieces 28
5.2 Cutting the workpiece with the pipe cutter 28
5.3 Reaming the workpieces 29
5.3.1 Reaming with cone reamer (up to 2“) 29
5.3.2 Reaming with blade reamer (2 ½“ - 4“)
29
5.4
Removing and installing the thread jaws from and in the thread-head 30
5.4.1 Automatic thread head (Fig. B)
30
5.4.2 Standard thread head (Fig. C) 30
5.4.3 Standard thread head (Fig. D) 31
5.5 Threads 31
5.6 Removing the workpiece 32
5.7 Cleaning after use 32
5.8 Install small die head adapter 32
