Two s stage d door llock d diagrams ccont’d, Two stage reverse polarity, Two stage adding actuators – Aastra Telecom 600 User Manual
Page 22

Page 18 - Astra 600
Two S
Stage D
Door LLock D
Diagrams ccont’d
(+) Door Lock wire
(+) Door Unlock wire
DRIVER DOOR
MOTOR
PASSENGER DOOR
MOTORS
15A FUSE
CUT
FACTORY
DOOR LOCK
MODULE
+12V
+12V
White wire
Green wire
Blue wire
Brown wire
Violet wire
DOOR LOCK CONNECT
O
R
DOOR LOCK
SWITCH
CUT
CUT
Blue/white wire
(-) PASSENGER
UNLOCK
Two Stage Reverse Polarity
DRIVER DOOR
MOTOR
PASSENGER DOOR
MOTORS
15A FUSE
+12V
+12V
White wire
Green wire
Blue wire
Brown wire
Violet wire
DOOR LOCK CONNECT
O
R
Blue/white wire
(-) PASSENGER
UNLOCK
Two Stage Adding Actuators
