4. Unscrew and remove the two large rear bolts B
and the six smaller bolts C.
5. Remove the bracket D and tighten up the six
smaller bolts C. Slide out the relevant plastic
spacer E.
6. Open the porthole, take out the inlet hose from the
drum and remove the polystyrene block fitted on the
door seal.
7. Fill the smaller upper hole and the two large ones
with the corresponding plastic plug caps supplied in
the bag containing the instruction booklet.
8. Connect the water inlet hose as described under the
paragraph «Water inlet».
All the different plug caps are supplied with the
appliance in the plastic bag containing the instruction
booklet.
41
C
C
B
D
HEC0003
B
C
C
HEC0023
E
HEC0010
HEC0005
Installation
