12
Type
EQU231VU-MKII
EQU231-MKII
EQU231TWIN-MKII
EQU131VU-MKII
EQU131-MKII
EQU215-MKII
2 31 Band: 1/3 octave, ISO spacing (2H series)
2 15 Band: 2/3 octave, ISO spacing (3H series)
2 31 Band: 1/3 octave, ISO spacing (2H series)
1 31 Band: 1/3 octave, ISO spacing (1H series)
2 15 Band: 1/3 octave, ISO spacing (1H series)
6. TECHNICAL SPECIFICATIONS
Slider travel 20mm with positive centre detente
(EQU231-MKII/EQU231VU-MKII/EQU131-MKII/EQU215-MKII)
45mm with positive centre detente
(only for EQU231TWIN-MK II)
60mm with positive centre detente
(EQU131VU-MKII/EQU215TWIN-MKII)
6dB or 12dB selectable
Active balanced XLR and 1/4" TRS
Unbalanced RCA
20k (bal.)
15k (unbal.)
14dBu
Active balanced XLR and 1/4" TRS
Unbalanced RCA
600
40Hz (12dB/oct) fixed-button type .
16KHz (12dB/oct) fixed-button type
20Hz to 50KHz at - 1.5dBu
0.01% (@ 1KHz , all VR at middle position)
110dB
95V-120VAC -60Hz
220V-240VAC -50Hz/60Hz
2 31 band, 1/3 octave, ISO spacing: 18W
2 31 band, 1/3 octave, ISO spacing: 18W
2 31 band, 1/3 octave, ISO spacing: 18W
1 31 band, 1/3 octave, ISO spacing: 9W
1 31 band, 1/3 octave, ISO spacing: 9W
2 15 band, 1/3 octave, ISO spacing: 9W
2 15 band, 1/3 octave, ISO spacing: 9W
483(W) 220(D) 44(H)(19" 8.66" 1.7")mm (1H series)
483(W) 220(D) 88(H)(19" 8.66" 3.5")mm (2H series)
483(W) 220(D) 132(H)(19" 8.66" 5.1")mm (3H series)
Range
Input connections
Output connections
Input impedance
Maximum input level
Output impedance
High pass filter
Low pass filter
Frequency response
THD + N %
S / N ratio
Power supply
Consumption
Dimensions
EQU231VU-MKII
EQU231-MKII
EQU231TWIN-MKII
EQU131VU-MKII
EQU131-MKII
EQU215-MKII
EQU215TWIN-MKII
1 31 Band: 1/3 octave, ISO spacing (2H series)
EQU215TWIN-MKII 2 31 Band: 1/3 octave, ISO spacing (2H series)
Input impedance 20kohm (bal)
15kohm (unbal)
