4.3 Input Current:
The maximum input current shall be less than 4.5A at 100~240Vac input
4.4 Effciency:
88% min. measured at 100Vac and 240Vac input voltage, full load
5 Output Characteristics
5.1 Output Power
Output Voltage Load Range Reguation Rated power
15V 0A 4.5A 14.5 ~ 15.5V 67W
16V 0A 4.5A 15.5 ~ 16.5V 72W
18V 0A 4.5A 17.5 ~ 18.5V 81W
18.5V 0A 4.5A 18 ~ 19V 84W
19V 0A 4.5A 18.5 ~ 19.5V 86W
19.5V 0A 4.5A 19 ~ 20V 88W
20V 0A 4.5A 19.5 ~ 20.5V 90W
5.2 Rated Power
This adapter is capable to support 90 Watts continuously at all specified conditions.
5.3 Ripple & Noise Voltage
Voltage 15V/16V/18V/19V at full load
Ripple & noise voltage 150mV
The ripple and noise are as follows when measure with Max. Bandwidth of 20MHz and
Parallel 10uF/0.1uF,crossed connected at testing point.
