Spire LUNAR II / SP517-1U - Manual (Page 13)

6. FAN SPECIFICATIONS
FAN MODEL: FD07015C1H3-Blower
1. Rated Voltage : 12VDC
2. Operating Voltage Range : 10.2 ~13.8VDC
3. Rated Speed : 4200RPM ±10％
4. Static Pressure : 3.58 mm-H
2
O
5. Air Flow : 33.8CFM
6. Rated Current : 0.3 AMP
7. Rated Power : 3.6 WATTS
8. Noise Level : 31.8 dB(A)
9. Operating Temperature : -10 to 70 Deg. C
10. Storage Temperature : -40 to 70 Deg. C
11. Bearing System : Dual Ball Bearing
12. Connector : 3 pin
13. Weight : 65.0 g
Page 13 / Version: 2
Spire Corp.
