3. Features and Specifications:
Main features:
Supports all new AM2/AM3/AM3+/FM1/FM2 micro-processors
Ø95x25mm sleeve fan for silent operation
High-density extruded heat-sink with large base for optimal heat conductivity
Specifications：
Dimensions
Heat sink : 77X85X34 mm
12VDC Fan : Ø 95x25mm
Material AL
Bearing Sleeve Bearing
Rated speed
Cooler 600~2200 RPM +/-10%
Single fan 600~2200 RPM +/-10%
Rated power 1.92 W
Noise level 10.0~26.0 dBA
Air flow 45.26CFM Max.
Current 0.16A
Life hours Sleeve: 30,000
Connector 4 PIN PWM(2510)
Application AMD: AM2/AM3/AM3+/FM1/FM2
TDP 95W
Thermal
resistance
0.347°C/W
Thermal type Stars-TIG780-50 grease
weight 238g(Cooler only)
