Spire COOLREEF PRO PWM / SP805S3-PWM - Manual (Page 10)

Version:A/0 Page 10 of12
Spire Corp.
Http://www.spirecoolers.com & Http://www.spirepower.com
Http://www.spire-corp.com
5. Fan Specification:
FAN MODEL: SF09025SRM4W2-PWM
1) Rated Voltage : 12VDC
2) Operating Voltage Range : 10.2 ~13.8VDC
3) Rated Speed（only fan） : 600~2200RPM ±10%
4) Static Pressure : 2.11 mm-H
2
O
5) Air Flow : 45.26 CFM Max.
6) Rated Current : 0.16 A
7) Rated Power : 1.92WATTS
8) MAX Noise Level : 10.0~26.0 dB(A)
9) Operating Temperature : -10 to 70 0 C
10) Storage Temperature : -40 to 70 0 C
11) Bearing System : Sleeve Bearing
12) Connector : 4 PIN PWM(2510)
13) Weight : 64.0g
