Spire STARFLOW / SP601S7 - Manual (Page 7)

Version:A/0 Page 7 of12
Spire Corp.
Http://www.spirecoolers.com & Http://www.spirepower.com
Http://www.spire-corp.com
3. Features and Specifications:
Main features:
Supports all new Intel LGA775/1155/1156 micro-processors
Ø 90x25mm Sleeve bearing fan for silent operation
High-density extruded heat-sink with large base for optimal heat conductivity
Specifications:
Dimensions
Heat sink : Ø 93*93*19.5mm
12VDC Fan : Ø 90*25mm
Material AL
Bearing Sleeve Bearing
Rated speed
Cooler 2500 RPM +/-10%
Single fan 2400 RPM +/-10%
Rated power 3.6W
Noise level 25.0 dBA
Air flow 40.9 CFM
Current(MAX) 0.3A
Life hours Sleeve: 30,000
Connector 3 pin(2510)
Application
Intel LGA 775/1155/1156 Cooler :
TDP(Watt) 65W
Thermal
resistance
0.386°C/W
Thermal type Stars-350 white grease (pre-applied)
weight 153g(Cooler only)
