5. Fan Specification:
FAN MODEL: SF09025SRM302-3
1) Rated Voltage : 12VDC
2) Operating Voltage Range : 10.2 ~13.8VDC
3) Rated Speed(Only fan) : 2400RPM ±10%
4) Static Pressure : 1.7 mm-H
2
O
5) Air Flow : 40.9CFM
6) Rated Current(max) : 0.3 A
7) Rated Power : 3.6WATTS
8) Noise Level : 25.0 dB(A)
9) Operating Temperature : -10 to 70 0 C
10) Storage Temperature : -40 to 70 0 C
11) Bearing System : Sleeve Bearing
12) Connector : 3 pin(2510)
13) Weight : 56.0 g
